photoartflightStudio Stacked Images
Posted on November 26, 2013
With it getting colder outside I was looking for images in the archives. One cold Winter Day last December, a friend came over to the studio for shooting some macro setup studio shots. When shooting closeup subjects, it is hard to get everything in focus, even at f/22 or f/32. Here are a series of stacked macro images shot with two different camera systems to show the depth of field you can get with Stacking images. For Short Stacks, you can try handholding, but for best results or Large Stacks, use a tripod and lock it down as best as you can. We were looking around the studio for subjects and came upon this deceased Robber Fly in a window. We positioned it on a Pussy Willow branch and printed out a slight gradated print for the background. We used a Speedotron Black Line power pack and dialed down the power for the f/stop we wanted to use. I used a Canon EOS 1D MkIV with a Canon 100mm f/2.8L Macro IS USM, 1/125 sec @ f/8 ISO 200 for some images. The other system I used was a Panasonic GH2 m43 camera body with an older Canon 200mm f/4 FD Macro lens @ 1/80 sec @ f/8 for the 4 image Short Stack and f/4 for the 51 image Large Stack. For stacked images, you start with the lens focused to your closest point and then shift focus farther back, shooting a series with a very slight focus shift as you go. The best way is to use a focusing rail to move your Camera & Lens at the same time instead of shifting focus on the lens, but these were shot by changing focus on the lens, which also works. Then I aligned the images in Photoshop. After Aligning, I Stacked the images in Photoshop. Depending on the number of layers in the stack, this can take a while to process. The stacked images here are a series of a Short Stack of 4 images, then a stack of 20 images and then a large stack of 51 images. Give it a try, especially on a cold Winter day.
Canon 200mm f/4 FD Macro lens @ 1/80 sec @ f/8 ISO 200 – 51 Image Large Stack
Canon 200mm f/4 FD Macro lens @ 1/80 sec @ f/8 ISO 200– 4 image Short Stack
Canon 400mm f/4 DO w/ 36mm extension tube @ 1/125 sec @ f/8 ISO 400 -Single Image, No Stack
A Little Different Macro – Canon MP-E 65mm
Posted on November 18, 2013
I went out to The Celery Farm Natural Area to photograph very small dried wildflowers. I took along my Canon MP-E 65 mm 1-5X Macro. This is a very specialized macro lens that starts at 1X and goes to 5X magnification. It is more like a lens with a variable extension tube zooming out for the increased magnification. I decided to add a 1.4X teleconverter to add a little more working distance. This adds just a little bit more working distance, in some cases the front element is less than an inch away from your subject, but every bit helps. With the 1.4X Teleconverter it makes this a 91mm f/4. I was using a Canon Macro Ring Flash MR-14 EX to light these subjects as I was shooting handheld. My camera body was a Canon 1D MkIV camera body, so with the 1.3 crop of the sensor, this also adds to the lens, making it 1.3X to about 6X. For the wildflowers I left it at 1.3X for most, then later I shot some areas of the wooden lookout tower at various magnifications to show the different magnifications. I used aperture priority for some where I wanted to get some background detail, while the ones I have with dark backgrounds I used Manual exposure to darken the background and let the flash light the subject.
Full image for an idea of scale and subject
One of the smaller dried wildflowers @ 1.3X, lit with ring lash, no ambient light, for darker background
Larger Dried Wildflower @ 1.3X, handheld, lit with ring flash for main exposure, ambient light for background 1/10 of a second
Dried Wildflower @ ~3X, handheld, lit with ring flash for main exposure, 1/80 sec ,positioned for dark background
Dried Wildflower Bud @ ~2X, handheld, lit with ring flash for main exposure, ambient light for background 1/60 of a second
Reference shot for examples of scale
~ 2X Magnification, Carriage bolt magnification detail
~ 4X Magnification,, Carriage bolt magnification detail
~ 6X Magnification, Wood grain and with slight crack in wood grain around Carriage bolt
Fall Photos
Posted on October 20, 2013
I spent the morning with a friend at the Greenway entrance to The Clery Farm Natural Area in Allendale, NJ. We were looking for Fall Still Life images in the fields. There had been a rain during the night so there were water droplets all around. All images were with the Canon 1D MkIV with the Sigma 150mm f/2.8 OS Macro. Because of the breeze I shot some images at f/4 to help stop the motion with a higher shutter speed and used a 2 shot image stack for the depth of field and also for exposure of the highlights.
Caterpiller Wreath
Posted on October 17, 2013
I found this rolled up caterpillar on a bench. I thought it was interesting with the spikes and colors. The caterpillar reminded me of a wreath. Canon 1D MkIV with the Sigma 150mm f/2.8 OS Macro. The caterpillar was in the shade so I used f/8 to get some depth of field for the spikes and tried to shoot straight down with the front of the lens parallel to the caterpillar to get as much in the plane of focus. I ended up with 1/30 of a second exposure at ISO 800 , handheld, so I shot a burst which enabled me to pick the sharpest exposure in the series. I believe it is a Smeared Dagger Moth Caterpillar, a stinging caterpillar. It uses poison filled bristles to defend itself.
Colors of Fall in the Northeast
Posted on October 14, 2013
I spent the last few days wandering around a few of my local shooting areas looking for local Fall Color. You do not have to go far, look around your own yard or local park, you might be surprised at what you find. Here are a few from my yard and The Celery Farm Natural Area, 107 acre fresh water wetland. All were taken with my Canon 1D MkIV and the Sigma 150 f/2.8 macro. The 150mm macro is a great lens and the right focal length for these. Most of the time I set an f/stop of f/2.8 if they were in the shade and increased to f/5.6 in brighter light. I wanted to keep a shallower depth of field to keep some backgrounds less obtrusive. I also tried to shoot straight in to my subjects (parallel) to maximize sharpness across the leaves. You do not have to travel far to get some Fall Color Images and it can also be a challenge to see what you can shoot.
-
- Colors of Fall
Spiders & More Spiders
Posted on October 7, 2013
It seems to be the season for spiders. Working in the yard I am coming across quite a few. The one from the other day enlarged its web to about 8 ft wide. Very poor light and windy, but here are a few quick captures, plus one from last week. With the poor light and the wind I had to use a high ISO and f/ stops from f/2.8 to f/5.6 to get something usable. All shot with a Sigma 150mm f/2.8 macro on a Canon 7D. Opened in Camera Raw with aggressive noise reduction. I have to find something besides spiders for next time. I also added one Dragonfly that I just came across and liked.
Spider & His Shadow
Posted on September 30, 2013
As I was working in the yard and cutting the lawn I spotted this Spider on the side of the house. When I was done he was still hanging around, so to speak. I tried shooting a few shots, but it was windy and it was in the shade. I upped the ISO to 1600, but I still needed more depth of field. I tried a 3 shot sequence to make a panorama and was about to give up. Then the sun broke through and cast his shadow. I liked that shot the best and was satisfied with what I got, so back to yard work. Keep trying different crops, lighting or other ways to capture your subject. Don’t settle for one quick shot. You will be surprised with what you come up with. Again this was taken with the Panasonic GH2 and the Canon FD 200mm f/4 macro with the FD to m43 lens adapter.
Water Droplets
Posted on September 29, 2013
A lot of photographers do not like it when it rains, cuts down on their photography. I like a rain showers, when it ends or just drizzles a little, it gives you an opportunity to go and add water droplets to your photos. It adds interest and dimension to leaves and other subjects. It is like a Treasure hunt and you can do it in your own yard or a local park. When shooting wet leaves, sometimes it helps to use a polarizing filter to cut down on the glare if the sun comes out. Most of the photos shown here were shot using the Panasonic GH2 m43 camera with an older manual focus Canon FD 200mm f/4 macro lens. I like using this combination for macro. With this combo it is like using an f/4 400mm macro that goes to 2X without extension tubes. Your depth of field is also extended because it is a 200 mm lens, but with the 2X crop factor of m43 giving you 400mm. Plus you are not right on top of your subjects, gives you a nice working distance. You just press in the exposure compensation and the image in your viewfinder zooms in for critical focus. Then you just touch the shutter button and it zooms out for the full image on the viewfinder. Also as you stop down, the image remains bright in the electronic viewfinder, but you also see the full depth of field of the aperture you set. After you shoot your shot you also instantly see a preview of what you just shot for a second and will give you “blinkies” on a bright area that might have gotten blown out so you can instantly compensate and reshoot a darker exposure. So enjoy and go out and look after a rain shower to see what you can find.
Web Browsing
Posted on September 28, 2013
I like a different kind of Web Browsing. It is fun to wander around either in my yard or parks looking for spider webs. Sometimes I get lucky and find nice webs with morning dew with interesting backgrounds & backlighting. But more often I find webs in difficult areas to get to or in really dark areas with bad light and wind blowing it around. If you keep an eye out for webs while you are out shooting other subjects, quite often you will come across them. Sometimes I try to get in as close as I can for more detail in the web and spider. Other times I back out to show more of the whole web. For whole webs you do not need a macro lens. If you want to get closer and do not have a macro lens, try extension tubes or achromatic filters. They work quite well on 70 – 200 or 300mm zooms or even 50mm normal lenses. You can even try a short extension tube on wide angle lenses. When shooting spiders close-up, try just moving up or down slightly to get different backgrounds. You do not have to move too much to get different background effects and density variations. Either way, give it a try and have fun.
Twenty four shot image stack assembled in Photoshop
One of My Favorite Macro Setups
Posted on September 19, 2013
I enjoy shooting a lot of closeup and macro shots. One setup I like when I do not want to carry a lot of gear and still have maximum flexibility, is a m4/3 camera body with adapters for my old manual Canon FD 200mm f/4 macro and Nikon 55mm macro. I am using a Panasonic GH2 body, but with the crop factor it is like using a 400mm f/4 macro, but with the depth of field of a 200mm macro, which is more depth of field than a 400mm. This helps when you get really close. Because my old macro lenses are manual focus, on the GH2 with the electronic viewfinder, I just push the control wheel, and zoom in for critical focus. Also as you are shooting you get a preview in the viewfinder of your shot, so you instantly see if any highlights are blown or if you need exposure compensation. With the articulating rear screen it also helps when your subjects are in difficult positions. Because the body is not stabilized I use my tripod when using the old manual focus lenses. The Olympus OM-D e-m5 or the new OM-D Pro bodies have stabilization in the bodies so using these lenses would then be on a stabilized setup which is an interesting. Using the old manual focus Nikon 55mm, with the crop factor, would be like a 110mm macro with amazing depth of field. The GH2 with the Panasonic 14-140mm & 100-300mm stabilized lenses, with the crop factor (2X) is like carrying 28- 280mm and 200-600mm in a lightweight package. I am quite impressed with image quality of both of these lenses and often carry the GH2 with one of them as a second backup setup when my main setup is a Canon body with long telephotos or macro lens. Gives the opportunity to shoot something wide if a 400mm is my main camera, or something far if my main camera has a macro lens. I shoot raw files and using Adobe Camera Raw adjust for sharpness and to control the noise. If I have to I can use up to 3200 – 6400 ISO. A lot of damselflies and dragonflies I shoot at my pond are late in the evening or early in the morning when they are not moving around yet, or after a rain shower when the light is low. If you access to a m43 body give it a try, it is a lot of fun.
